H_16xRJ45+2xFiber Sending Card

Description of the

H_16xRJ45 2xFiber Sending Card

Output card for the H-series controllers.

The output card can manage up to 10.4 million pixels (Max. width/height: 10240 pixels)

16x RJ45 Gigabit Ethernet outputs:

• With 8-bit colour depth: 650000 pixels per port
• At 10-bit colour depth: 320000 pixels per port
• Hot backup capable

2x OPT outputs:

• Supports singlemode & multimode transmission
• OPT1 mirrors the signal of the Ethernet ports 1-8
• OPT2 mirrors the signal of the Ethernet ports 9-16
